VM600 PNR 200-560-000-113 Vibro-meter DCS Monitoring Module

• Brand
  Vibro-meter
• Model
  VM600 PNR 200-560-000-113
• Product Name
  Extended Machinery Condition Monitoring Module
• Place of Origin
  Switzerland
• Customs HS Code
  85437090
• Power Supply
  24 VDC
• Dimensions
  262 mm (6U) × 40 mm × 187 mm
• Weight
  0.39 kg
• Operating Temperature
  0 ℃ ~ +65 ℃
• Storage Temperature
  -40 ℃ ~ +85 ℃
• Warranty
  12 month
• Product Status
  New and original

Vibro-meter VM600 PNR 200-560-000-113 Product Introduction & Technical Specifications

Electrical Parameters

Rated Power Supply: 24 VDC (18 VDC ~ 58 VDC wide range)

Typical Operating Current: 1.2 A at 24 VDC

Dynamic Input Channels: 16 independent differential measurement channels

Tachometer Auxiliary Inputs: 4 speed/phase reference channels (1–100,000 RPM measuring range)

Input Signal Range: 0.8–500 V peak-peak, bandwidth 0.3 Hz ~ 50 kHz

Sampling Performance: Max 6400-line high-resolution FFT spectrum output, minimum 100ms refresh cycle

Analog Output: 16 isolated 4–20mA process outputs

Relay Output: Multi-channel configurable alarm/trip dry contact relays

Communication Interface: Rack backplane bus, compatible with Modbus TCP/RTU, PROFINET via CPUM controller card

Sensor Excitation: On-board regulated power supply for IEPE vibration sensors

VM600 PNR 200-560-000-113 Vibro-meter  Standard Wiring Method

Step 1 Rack Backplane Connection

Insert the VM600 200-560-000-113 card into the designated slot of ABE04x/ABE056 rack, ensure rear backplane connector fully locked to complete internal power and communication bus connection.

Step 2 Vibration Sensor Signal Wiring

Use shielded twisted pair cables to connect accelerometer/eddy current probes to module rear terminal blocks; separate low-level sensor cables from high-power AC wiring to eliminate EMI. Ground cable shield single-ended at cabinet earth bar only.

Step 3 Tachometer Speed Signal Wiring

Route magnetic pickup or proximity probe tachometer signals to auxiliary speed input terminals; limit single cable length within 500 meters to guarantee speed measurement accuracy.

Step 4 Analog Output Wiring (4–20mA to DCS/PLC)

Connect each 4–20mA output channel to external control system analog input modules; configure external loop power supply according to system loop diagram.

Step 5 Alarm Relay Output Wiring

Wire dry contact relay terminals to equipment interlock trip circuits; relay contacts carry no internal power, independent external control power must be configured.

Step 6 Cabinet Protective Grounding

Connect module dedicated ground terminal and all cable shielding layers to cabinet common protective earth busbar to suppress static and common-mode interference.

Step 7 Pre-Power-On Inspection

1. Verify all terminal wiring polarity and channel sequence are correct without short circuits.

2. Tighten all screw terminals to avoid loose contact under equipment vibration.

3. Complete offline sensor signal simulation test to validate measurement and alarm functions before unit formal operation.

4. Download configuration parameters via VM600 MPSx software after power-on, confirm normal data upload to VibroSight monitoring platform.

5. Typical Application Scenarios

Steam & gas turbine safety monitoring; centrifugal compressor vibration protection; generator rotor condition monitoring; large industrial fan & pump predictive maintenance; combustion dynamic monitoring for combined-cycle power plants; offshore oil & gas rotating machinery protection systems.

VM600 PNR 200-560-000-113 Vibro-meter  Core Product Advantages

1. High Channel Density: 16 dynamic measurement channels on single card, reduces rack slot occupation and cabinet space cost.

2. SIL 2 Functional Safety Certification: Meets critical machinery protection safety standards for power and petrochemical main equipment.

3. Full Sensor Self-Diagnosis: Real-time detection of probe open circuit, short circuit and signal amplitude abnormality with instant alarm output.

4. Synchronous Multi-Parameter Analysis: Simultaneous order tracking, waveform capture and high-precision FFT spectrum analysis for bearing, rotor and combustion fault diagnosis.

5. Hot-Swap Support: Cards can be inserted/removed under powered rack without system shutdown, convenient for online maintenance and spare part replacement.

6. Wide Signal Compatibility: Supports all mainstream vibration, displacement, dynamic pressure and tachometer sensors without extra signal converters.

7. Stable Industrial EMC Performance: Reinforced isolation and shielding design, strong anti-electromagnetic interference in high-voltage cabinet environments.

8. Unified Software Management: Fully matched with VibroSight and VM600 MPSx configuration software for one-shot parameter setup and data logging.、
