Triconex 5351 Analog Input Module

• Brand
  Triconex
• Model
  5351
• Product Name
  TMR Analog Input Module / TriPak 1 Assembly
• Country of Origin
  United States
• HS Code
  8538909100
• Dimensions
  450mm(Height)×200mm(Width)×150mm(Depth)
• Weight
  3.0 kg (6.61 lbs)
• Operating Temperature
  -40°C to 70°C (-40°F to 158°F)
• Storage Temperature
  -40°C to 85°C (-40°F to 185°F)
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

Triconex 5351 Power and Input Specifications

System Rated Voltage: 24V DC nominal power routed directly via the internal chassis backplane

Input Signal Type: 4–20 mA DC proportional analog current loops

Total Points/Channels: High-density architecture supporting up to 32 independent analog input channels per TriPak sub-module

Input Filter Frequency: Configured with a 16 Hz low-pass input filtering threshold to reject high-frequency line noise

Triconex 5351 Wiring and Connection Methods

Field Interface Terminal Board: Interfaces via a dedicated external field termination assembly (FTA) block connected through high-density backplane ribbon cables.

Wiring Connection Type: Employs industrial compression screw-clamp termination blocks on the companion FTA, supporting wire sizes from 24 AWG down to 12 AWG (0.2 mm² to 2.5 mm²).

Shielding Requirements: Shielded twisted-pair (STP) instrument cabling must be used for field loops, with all drain shields cleanly terminated at the structural panel instrument ground bus.

Triconex 5351 System Processing & Features

TMR Triple Voting Processing: Employs three independent microprocessors to read and vote on field data, eliminating any single point of failure.

On-board Diagnostics: Executes continuous background self-test loops to detect sensor degradation, open-circuit faults, and out-of-range loop currents.

Online Hot-Swapping: Supports online module level removal and replacement (hot-swapping) on a live system without disrupting active field instrumentation wiring.

Front Panel Indicators: Integrated physical LEDs provide real-time diagnostic status updates for Module Pass, Fault, Active, and Channel Status.

•
