ICS TRIPLEX T8850 Trusted 40-Channel Analog

• Brand
  ICS TRIPLEX
• Model
  T8850
• Product Name
  Trusted 40-Channel Analog
• Country of Origin
  United Kingdom
• HS Code
  8538909100
• Dimensions
  300mm(Height)×125mm(Width)×65mm(Depth)
• Weight
  0.8 kg
• Operating Temperature
  0°C to 60°C (32°F to 140°F)
• Storage Temperature
  -25°C to 70°C (-13°F to 158°F)
• Power Supply
  24 VDC
• Warranty
  12 month
• Product Status
  New and original

ICS TRIPLEX T8850 Power and Input Specifications

Nominal System Operating Voltage: 24V DC / 48V DC

Operational Input Voltage Range Tolerance: Flexible dual support handling ranges from 18V DC to 32V DC and 18V DC to 60V DC

Field Power Tracking Diagnostics: Equipped with on-board LED indicators that instantly verify active field power supply status across the board segments

Output and Channel Specifications

Total Channel Capacity: 40 independent field device output channels per assembly

Output Channel Wiring Profile: Standard industry 2-wire field device connections

Current Power Rating Limits: Rated for up to 2.0A maximum current output per individual channel

Maximum Total Current Assembly Capacity: 40A maximum total aggregated current load handling across all combined channels

ICS TRIPLEX T8850 Wiring and Connection Methods

Field and Power Connection Interfacing: Utilizes heavy-duty industrial screw clamp terminals on both field-side and power-side routing ports.

Wire Size Allowance Gauge: Accepts a broad range of standard industrial wiring, from 30 AWG up to 12 AWG (0.05 mm² to 2.5 mm² structural core size).

Terminal Installation Tightening Torque: Recommended terminal screw torque specification set to 0.5 N·m (4.4 in-lb) for secure, vibration-proof connections.

Module Core Interconnect Interface: Links directly into the primary Trusted rack using specialized multi-way ribbon cable connectors, eliminating time-consuming point-to-point pin soldering or discrete jumper schemes.

ICS TRIPLEX T8850 Product Features

Advanced Cross-Channel Isolation: Organizes the 40 channels into 5 isolated groups of 8 channels each, protecting adjacent groups from localized short-circuits.

SmartSlot Dynamic Hot Replacement: Natively supports "one-to-many" hot-swapping configurations, enabling safe replacement of active TMR output modules without losing field device control.

High Signal Integrity: Features ultra-low resistance connection pathways, maintaining precise signal propagation across both discrete digital signals and analog 4-20mA monitoring loops.

High Inrush Tolerance: Designed to easily handle high-current inductive and capacitive inrush loads typical of industrial control valves and heavy solenoid coils.

•
