XP-504-15-A10-A01-2B EATON Industrial Panel PC HMI

• Brand
  EATON
• Model
  XP-504-15-A10-A01-2B
• Product Name
  XP-504 Series 15.6-inch Industrial Panel PC HMI
• Place of Origin
  Germany
• HS Code
  84715040
• Dimensions
  5.0 kg
• Weight
  404mm (W) × 83mm (D) × 273mm (H)
• Operating Temperature
  0°C ~ +55°C
• Storage Temperature
  -20°C ~ +65°C
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

Eaton XP-504-15-A10-A01-2B Introduction and Technical Specifications

Electrical Parameters

Operating Voltage: 10VDC ~ 36VDC wide industrial DC input range

Rated Working Current: Typical 1.75A @24VDC

Onboard Processor: Industrial high-stability 1.65 GHz processor

Hardware Configuration: 4 GB RAM, 32 GB built-in solid-state storage, support for CFast extended storage

Operating System: Windows Embedded industrial system with upgraded Galileo runtime license

Communication Interfaces: Dual Gigabit Ethernet ports, RS232/RS485 serial interfaces, multiple USB 3.0 ports

Built-in comprehensive protection including overvoltage, undervoltage, reverse polarity and overcurrent protection to resist industrial power fluctuations

XP-504-15-A10-A01-2B EATON Product Advantages

1. Upgraded iterative model with optimized system algorithm, higher operational stability and lower failure rate than previous generation products.

2. Ultra-wide industrial voltage input and expanded working temperature range, stronger adaptability to complex and variable industrial field environments.

3. 15.6-inch high-definition widescreen resistive touch display, delivering sensitive, accurate and durable touch operation for long-term industrial use.

4. IP65 front panel protection effectively resists industrial dust, water splashes, oil stains and corrosive substances.

5. Rich and complete communication interfaces support multi-protocol docking and multi-device networking, with excellent system compatibility and scalability.

6. Integrated all-in-one compact structure saves control cabinet space and simplifies on-site wiring layout.

7. Industrial-grade rugged hardware design enhances anti-vibration and anti-interference capability, reducing long-term operation and maintenance costs.

XP-504-15-A10-A01-2B EATON Wiring & Installation Method

Power Wiring: Rear terminal block type DC power wiring, compatible with 10–36VDC industrial power supply, equipped with dedicated grounding terminal for operational safety

Signal Wiring: Standard RJ45 Gigabit Ethernet wiring for network communication, DB9 serial port wiring for device data transmission, USB interfaces for peripheral connection and program debugging

Installation Method: Standard flush panel embedded mounting, matched with reserved fixing holes for quick and firm cabinet installation; easy disassembly and assembly for daily inspection, debugging and maintenance

•
