XP-503-15-A10-A00-1B EATON 15.6-inch Panel PC HMI

• Brand
  EATON
• Model
  XP-503-15-A10-A00-1B
• Product Name
  XP-503 Series 15.6-inch Industrial Panel PC HMI
• Place of Origin
  Germany
• HS Code
  84715040
• Dimensions
  404mm (W) × 83mm (D) × 273mm (H)
• Weight
  4.95 kg
• Operating Temperature
  0°C ~ +50°C
• Storage Temperature
  -20°C ~ +60°C
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

Eaton XP-503-15-A10-A00-1B Introduction and Technical Specifications

Electrical Parameters

Operating Voltage: 10VDC ~ 36VDC wide industrial DC voltage range

Rated Working Current: Typical 1.8A @24VDC

Processor: 1.65 GHz industrial-grade processor

Memory & Storage: 4 GB RAM, 32 GB built-in storage, supports extended CFast storage

System Platform: Windows Embedded Standard 7 with Galileo runtime license

Communication Interfaces: Dual Ethernet ports, RS232/RS485 serial ports, multiple USB 3.0 ports

Built-in overvoltage, overcurrent and reverse polarity protection for industrial power supply fluctuations

XP-503-15-A10-A00-1B EATON Product Advantages

1. Wide-range DC voltage input design adapts to various industrial power supply conditions with strong power fluctuation resistance.

2. High-definition 15.6-inch widescreen display with stable touch response, realizing intuitive and accurate on-site operation and monitoring.

3. High-performance hardware configuration and embedded industrial system ensure stable long-term operation without crash or lag.

4. IP65 front panel protection effectively resists industrial dust, water splash and oil pollution, improving environmental adaptability.

5. Rich integrated communication ports support multi-device docking and multi-protocol communication, with strong system compatibility.

6. Compact integrated panel structure saves cabinet space and simplifies on-site wiring layout.

7. Professional industrial rugged design features shock resistance and electromagnetic interference resistance, reducing field failure rate and maintenance cost.

XP-503-15-A10-A00-1B EATON Application Scenarios

Mainly applied in industrial factory automation production lines, process monitoring systems, mechanical equipment control terminals, packaging and printing automation, chemical and energy industrial control scenarios. It is widely used as on-site HMI monitoring and operation terminal for various automated control systems requiring stable and long-term continuous operation.

XP-503-15-A10-A00-1B EATON Wiring & Installation Method

Power Wiring: Rear terminal block DC power wiring, supporting 10–36VDC industrial power access, equipped with dedicated grounding terminal for safe operation

Signal Wiring: Standard RJ45 Ethernet wiring for network communication, DB9 serial port wiring for equipment data transmission, USB interface for peripheral device connection and program debugging

Installation Method: Flush panel mounting design, suitable for cabinet embedded installation; standardized mounting holes ensure firm and neat on-site assembly, convenient for daily inspection and maintenance

•
