3500/93 135813-01 Bently Nevada Display Interface I/O Module

• Brand
  Bently Nevada
• Model
  135813-01
• Product Name
  Display Interface I/O Module (3500/93)
• Dimensions
  241.3 mm × 24.4 mm × 241.8 mm
• Weight
  0.4 kg
• Place of Origin
  USA
• HS Code
  85423190
• Operating Temperature
  -20°C to +65°C
• Storage Temperature
  -40°C to +85°C
• Power Supply
  0.65 A
• Warranty
  12 month
• Status
  original

135813-01 Bently Nevada Functions

Product Type: 3500/93 Display Interface I/O Module for Bently Nevada 3500 machinery protection rack;

Core Function: Serves as a data gateway connecting the 3500 rack assembly and local display unit, delivering real-time machinery monitoring data through the RS422 interface;

Data Transmission: Acquires vibration, axial position, rotational speed, keyphasor and relay status signals from all monitoring modules within the 3500 rack and transmits these measurements to the local display;

Alarm & Event Management: Supports retrieval of system event logs, alarm history, channel status and fault diagnostic information for visual presentation on the display screen;

Communication Support: Adopts Bently Nevada proprietary protocol and Modbus protocol to facilitate bidirectional data exchange;

System Configuration: Cooperates with 3500 rack configuration software to finish parameter definition and display-related function setup;

Compliance: Built in accordance with API 670 specifications for industrial machinery protection systems;

Diagnostic Function: Constantly checks the communication link integrity between the rack and display, and triggers alerts for communication breakdowns or module anomalies;

Application: Deployed on turbines, compressors and other rotating assets to provide on-site visual indication of machinery protection conditions.

135813-01 Bently Nevada Application Scenarios

This unit is the display interface I/O module for the Bently Nevada 3500 machinery protection system. It is installed alongside the 3500 rack to enable local data visualization and status interaction.

Turbine monitoring: Deployed on steam turbines and gas turbines to present real-time shaft vibration, axial position, rotational speed and alarm status.

Centrifugal compressor protection: Adopted for oil & gas and petrochemical process compressors to deliver continuous machinery condition monitoring and local alarm indication.

Centrifugal pump & fan systems: Applied to large high-speed pumps and industrial fans in power and chemical plants, allowing field operators to read equipment health data locally.

Generator set monitoring: Suitable for industrial power generation assets to monitor keyphasor signals and relay status of rotating machinery.

Heavy-duty rotating equipment for refining and chemical industries: Enables on-site maintenance staff to access event logs, fault histories and channel status without connecting to a remote workstation.

Offshore oil & gas facilities: Integrated into rotating machinery protection systems on offshore platforms for local display of machinery protection parameters.

Large rotating assets in paper and metallurgical plants: Provides on-site status visualization for critical production rotating equipment.
