ABB 1TNA920611R0002 Interface Module

• Brand
  ABB
• Model
  1TNA920611R0002
• Product Name
  Interface Module / Signal Converter
• Country of Origin
  France
• HS Code
  85369010
• Dimensions
  75 mm (Height) x 12 mm (Width) x 60 mm (Depth)
• Weight
  0.05 kg (50 grams)
• Operating Temperature
  -20°C to +60°C (-4°F to 140°F)
• Storage Temperature
  -40°C to +80°C (-40°F to 176°F)
• Power Supply
  24VDC
• Warranty
  12 month
• Product Status
  New and original

ABB 1TNA920611R0002 Technical Specifications

Input & Output Ratings

Input Configuration: Standard industrial control voltage/current loops (typically supports 24V DC discrete inputs or standard 4-20mA / 0-10V analog signals depending on the specific application configuration).

Output Configuration: Clean, isolated output signal with minimal insertion loss, rated for standard control system logic levels.

Isolation Voltage: High dielectric isolation between input, output, and power supply circuits to prevent ground loops.

ABB 1TNA920611R0002 Key Product Advantages

Space-Saving Design: The ultra-slim profile maximizes DIN-rail space, allowing for high-density installations within control cabinets.

High Reliability & Isolation: Superior galvanic isolation protects sensitive control room electronics from field-side voltage surges and electrical noise.

Industrial Durability: Built using premium, flame-retardant materials that withstand harsh temperatures and industrial vibrations.

Global Compliance: Features international certifications (such as CE, UL, and RoHS) ensuring compliance with strict global safety and environmental standards.

Maintenance-Free Connection: The engineered clamping mechanism ensures long-term contact pressure, eliminating the need for periodic retightening.

ABB 1TNA920611R0002 Wiring & Connection Method

This module utilizes a Screw Clamp Connection (or Spring-Clamp / Push-In depending on the specific terminal block variant chosen).

Wiring Type: Top-entry or side-entry wiring for easy cabinet maintenance.

Wire Size Compatibility: Accepts solid or stranded wires ranging from 0.2 mm² to 2.5 mm² (AWG 24-12).

Tightening Torque: Recommended 0.4 to 0.6 Nm for screw versions to ensure a vibration-proof, gas-tight electrical contact.

•
