COM-MPB2-TP EATON DCS communication board

• Brand
  EATON
• Model
  COM-MPB2-TP
• Product Name
  Modular Power Distribution & Protection Terminal Module
• Country of Origin
  United States
• HS Code
  85369000
• Dimensions
  115mm×78mm×36mm
• Weight
  0.75kg
• Operating Temperature
  -20℃ to +70℃
• Storage Temperature
  -40℃ to +85℃
• Power Supply
  120-277V
• Warranty
  12 month
• Product Status
  New and original

EATON COM-MPB2-TP Product Introduction & Technical Specifications

Input and Output Parameters

Power Input: 120-277V AC wide voltage input, rated frequency 50/60Hz, maximum rated current 30A

Power Output: 120/240V AC stable output, supporting high-frequency signal transmission up to 30kHz

Signal & Communication Interface: Built-in Ethernet, RS232 and CAN bus interfaces, supporting Modbus, EtherNet/IP and multiple industrial communication protocols

Protection Performance: Equipped with overcurrent, overload and short-circuit protection, with 10kA short-circuit breaking capacity

Wiring Mode

It adopts push-in screw terminal wiring design for fast and reliable cable connection with clear polarity and function marking to avoid wiring errors. It supports standard front hard wiring for on-site power and signal connection. The integrated backplane docking structure is compatible with guide rail installation, realizing integrated power supply and signal wiring inside the control cabinet. Shielded cables are recommended for high-frequency signal wiring to ensure transmission stability.

Compatibility & Matching Accessories

It is fully compatible with Eaton low-voltage power distribution series products and industrial control modules, and can be matched with Eaton automation control systems, circuit breakers and relay units. Standard supporting accessories include dedicated DIN mounting guide rails, terminal insulating baffles, fixed fasteners and signal adapter terminals. It supports both original Eaton supporting accessories and qualified third-party compatible accessories for system assembly, renovation and upgrade.

Application Scenarios

It is widely used in low-voltage power distribution and signal transmission of industrial automation control systems. It is applicable to power supply protection and high-frequency signal connection for mechanical equipment in manufacturing, metallurgy, mining and cement industries. It also serves as a key power distribution and communication docking module for intelligent equipment, building automation and process control systems in chemical, water treatment and infrastructure fields.

Core Product Advantages

This module adopts an integrated modular design, combining power distribution, circuit protection and signal communication in one unit to save cabinet installation space. It supports wide-range AC voltage input with strong voltage fluctuation adaptability. The built-in multi-level protection mechanism effectively avoids equipment damage caused by circuit faults and improves system safety. It features excellent high-frequency signal transmission stability and anti-interference capability. The standardized mounting structure enables fast installation and replacement, reducing system maintenance costs and downtime. It has strong protocol compatibility and can seamlessly connect with mainstream industrial automation systems.
