ABB UBC717BE101 3BHE021887R0101 communication module

• Brand
  ABB
• Model
  UBC717BE101
• Product Name
  85423190
• Country of Origin
  Switzerland
• HS Code
  85423190
• Dimensions
  125mm×85mm×40mm
• Weight
  0.85kg
• Operating Temperature
  -20℃ to +70℃
• Storage Temperature
  -40℃ to +85℃
• Part Number
  3BHE021887R0101
• Warranty
  12 month
• Product Status
  New and original

ABB UBC717BE101 3BHE021887R0101 Product Introduction & Technical Specifications

Input and Output Parameters

Power Input: 24VDC industrial power supply with ±20% tolerance, maximum power consumption ≤ 11W

Signal Input: Multi-channel analog and digital signal inputs, supporting on-site equipment status sampling, voltage and current signal collection for medium-voltage drive systems

Signal Output: Configurable control output and status feedback output, used for driving logic execution and system operating status feedback

Communication Interface: Equipped with Ethernet and dedicated bus interfaces, supporting TCP/UDP/IP and ABB dedicated industrial communication protocols

Isolation Performance: 2500VAC high dielectric isolation design between power circuit and signal circuit, effectively resisting industrial electromagnetic interference and voltage surge impact

Wiring Mode

It supports dual standard wiring methods. Front screw terminal hard wiring is adopted for on-site signal access, with clear marking of signal points and polarities to prevent wiring errors. Backplane plug-in integrated wiring is used for cabinet internal assembly, realizing one-time completion of power supply and bus communication connection. Shielded cables are recommended for all analog and weak current signal wiring to enhance system anti-interference capability.

Compatibility & Matching Accessories

It is specially compatible with ABB ACS2000 series medium-voltage variable frequency drives, and matches perfectly with supporting drive power units and auxiliary monitoring modules. Standard supporting accessories include dedicated mounting guide rails, terminal insulating baffles, original connecting terminals and backplane adapter plates. It supports original ABB standard accessories and qualified third-party compatible accessories for equipment maintenance, replacement and system upgrading.

Application Scenarios

It is mainly used as the core main control component for ABB ACS2000 medium-voltage inverter systems. Widely applied to medium and high-power variable frequency speed regulation and energy-saving control scenarios in metallurgy, mining, cement, chemical industry and water treatment industries. It also serves as a key control unit for industrial fan, water pump and mechanical transmission variable frequency control systems, ensuring stable and efficient operation of medium-voltage industrial drive equipment.
