Description
-
BrandGE
-
ModelIS220PCNOH1B
-
Product NameMARK VIe CANopen Communication I/O Pack Module
-
Country of OriginUnited States
-
HS Code8537101190
-
Dimensions171mm×108mm×44mm
-
Weight1.13kg
-
Warranty12 month
GE IS220PCNOH1B Product Overview and Technical Specifications
Electrical Parameters
The module adopts standard industrial DC power supply with a rated operating voltage of 24VDC, and the stable input voltage range is 18VDC to 30VDC. It features low power consumption design with stable running current under rated working conditions. It supports a maximum communication baud rate up to 1Mbps and can connect up to 127 CANopen network nodes. Built-in electrical isolation and anti-surge protection circuits effectively resist electromagnetic interference in power plant environments, ensuring stable and error-free long-distance data transmission.
Wiring Method
The module adopts standard terminal block wiring mode for power supply and signal circuits. The 24VDC power supply is connected through dedicated power terminals with positive and negative polarity identification to ensure correct power input. Dual CAN communication ports adopt shielded twisted-pair wiring, which is connected to field CANopen devices in bus topology. Standard grounding terminals are equipped for system grounding and anti-interference shielding grounding, effectively reducing signal noise and improving communication stability. The wiring layout is standardized and intuitive, facilitating quick on-site wiring inspection and maintenance.
Core Product Advantages
It features perfect compatibility with GE MARK VIe turbine control systems with zero adaptation cost. Dual CAN port design supports redundant communication backup and improves system communication reliability. It supports full-function CANopen standard and extended protocols with large node capacity and high transmission efficiency. It adopts hot-swap design, allowing online module replacement without system shutdown to reduce equipment downtime. Built-in real-time communication self-diagnosis function can quickly locate network faults and abnormal node status. Industrial-grade anti-interference and anti-vibration design ensures long-term stable operation in complex electromagnetic environments of power plants, with low failure rate and excellent operational consistency.
Application Scenarios
It is mainly applied in communication expansion and external device connection of GE MARK VIe turbine control systems. It is widely used in combined cycle power plants, thermal power generation units, gas turbine and steam turbine industrial control systems. It is suitable for data communication access of CANopen protocol-based sensors, actuators and auxiliary control equipment in power industry. It also applies to industrial energy equipment transformation, system function expansion and multi-device integrated monitoring scenarios, providing reliable communication gateway support for intelligent and integrated turbine control systems.
Temperature & Environmental Parameters
The continuous operating temperature range is -20°C to +70°C, adapting to conventional indoor working environments of power plant control cabinets. The storage temperature ranges from -40°C to +85°C for spare parts storage and cross-regional transportation. It operates reliably under 5% to 95% non-condensing relative humidity. The industrial-grade dustproof structure meets standard cabinet environmental adaptability requirements, resisting slight vibration and dust erosion during long-term continuous operation.
