Description
-
BrandGE
-
ModelIS200JPDMG1A
-
Product NameMark VI DC Power Distribution Module
-
Place of OriginUnited States
-
HS Code8537101190
-
Dimensions165.1mm×178mm× 40mm
-
Weight2.6kg
-
Input120/240 VAC
-
Output25A
-
Temperature-30°C to +65°C
-
Warranty12 month
-
Brand NewNEW AND ORIGINAL
GE IS200JPDMG1A Product Overview and Technical Specifications
Temperature & Environmental Parameters
The continuous operating temperature range is -30°C to +65°C, adapting to complex temperature environments of power plant control cabinets. The storage temperature ranges from -40°C to +85°C for spare parts storage and long-distance transportation. It operates reliably under 5% to 95% non-condensing relative humidity. The industrial-grade circuit board coating and reinforced structure resist dust, slight vibration and electrical corrosion, and comply with Class I Division 2 hazardous environment safety standards for industrial field applications.
Core Product Advantages
It features perfect compatibility with GE Mark VI turbine control systems with no adaptation required. Dual redundant power input design effectively prevents system power failure and improves overall system operational reliability. Integrated multi-level protection mechanisms including overcurrent, short circuit and voltage anomaly protection maximize the safety of control equipment. Equipped with real-time power status LED indicators for intuitive operation status judgment and rapid fault location. Industrial-grade wide-temperature design and anti-vibration structure adapt to harsh power plant working conditions. The integrated power distribution structure simplifies cabinet wiring, reduces intermediate failure points and lowers system maintenance costs.
Application Scenarios
It is mainly applicable to power distribution and power supply protection of GE Mark VI turbine control systems. It is widely deployed in combined cycle power plants, thermal power generation units, gas turbine and steam turbine control cabinets. It is used for centralized power supply management of various I/O boards, communication modules and control accessories in power industrial control systems. It is also suitable for power safety protection and power quality optimization of key industrial automation control equipment in energy and heavy industry fields, ensuring stable and reliable operation of core control loops.
Wiring Method
