Vibro-Meter VM600 MPC4 200-510-078-115 DCS protection card

• Brand
  VIBRO-METER
• Model
  VM600 MPC4
• Product Name
  200-510-078-115
• Country of Origin
  Multi-Channel Machinery Protection & Monitoring Module
• HS Code
  Switzerland
• Dimensions
  262mm×20mm×187mm
• Weight
  0.40kg
• Operating Temperature
  -20℃ to +70℃
• Storage Temperature
  -40℃ to +85℃
• Part Number
  200-510-078-115
• Warranty
  12 month
• Product Status
  New and original

VIBRO-METER VM600 MPC4  200-510-078-115 Product Introduction & Technical Specifications
Input and Output Parameters

Power Input: Powered by VM600 rack dedicated power supply (+5VDC and ±12VDC), low power consumption design

Signal Input: 4 programmable dynamic signal channels, supporting acceleration, velocity and displacement sensor signals; 2 independent tachometer speed and phase reference input channels; analog input range covers 0~±20VDC, with amplitude accuracy up to ±1% full scale

Signal Output: Buffered raw signal output via front-panel BNC interface; programmable alarm and danger status relay output for system interlock and protection trigger

Processing Performance: Supports programmable broadband and narrowband filtering, order tracking amplitude and phase synchronous monitoring, with adaptive threshold judgment function

Isolation Performance: Industrial-grade electrical isolation between channels and power circuits, effectively resisting on-site electromagnetic interference and ensuring measurement accuracy

Wiring Mode

It adopts dual wiring designs including rear terminal hard wiring and front BNC quick wiring. Rear standard terminals are used for long-term fixed connection of field sensors and power signals with clear functional marking to avoid wiring errors. Front BNC interfaces are dedicated for temporary signal detection and equipment debugging. All signal wiring supports shielded cable connection to improve anti-interference capability. The power and signal circuits are wired separately to prevent signal crosstalk and ensure long-term stable signal transmission.

Compatibility & Matching Accessories

It is fully compatible with VIBRO-METER VM600 series rack systems, supporting matching with various vibration sensors, speed sensors and system communication modules. Standard supporting accessories include dedicated rack fixing brackets, signal shielding terminals, BNC adapter connectors and insulating accessories. It supports original VIBRO-METER standard accessories and qualified third-party compatible accessories for system assembly, maintenance, module replacement and functional upgrading.

Application Scenarios

It is widely used for condition monitoring and safety protection of rotating machinery in industrial core scenarios. Mainly applicable to power generation, petrochemical, metallurgy, cement and mining industries, monitoring key equipment such as steam turbines, gas turbines, fans, pumps and compressors. It provides real-time vibration, speed and phase data analysis, realizes fault early warning and automatic shutdown protection, and supports predictive maintenance of industrial rotating equipment to ensure the safe and efficient operation of production units.

Core Product Advantages

This module adopts high-precision DSP real-time processing technology to ensure accurate and fast collection and analysis of equipment vibration and speed signals. Multi-channel independent programmable design meets diversified monitoring demands of rotating machinery. It supports adaptive alarm threshold adjustment, which can dynamically match different operating conditions of equipment and reduce false alarms. Standard rack-mounted compact structure saves cabinet space and facilitates centralized system integration. Equipped with front LED status indicators and BNC debugging interface for convenient on-site observation and signal debugging. It complies with industrial SIL safety specifications, providing reliable mechanical protection and effectively avoiding equipment failure and shutdown risks caused by abnormal operation.
