05701-A-0361 Honeywell DCS Control Module

• Brand
  Honeywell
• Model
  05701-A-0361
• Product Name
  Industrial Analog Signal Acquisition & Engineering Control Module
• Country of Origin
  United States
• HS Code
  85423190
• Dimensions
  116mm×81mm×37mm
• Weight
  0.76kg
• Operating Temperature
  -20℃ to +70℃
• Storage Temperature
  -40℃ to +85℃
• Power Supply
  24 VDC
• Warranty
  12 month
• Product Status
  New and original

Honeywell 05701-A-0361 Product Introduction & Technical Specifications

Input and Output Parameters

Power Input: 24VDC industrial power supply with ±20% tolerance, low power consumption design

Signal Input: Supports standard 4-20mA analog current signals, compatible with catalytic bead, infrared and electrochemical gas sensors; covers multiple detection ranges for combustible and toxic gases

Signal Output: Isolated digital status output and processed analog signal output for upper system data analysis, alarm judgment and interlock control

Communication Performance: Supports automatic identification and configuration with Honeywell Experion PKS system, realizing fast data interaction and parameter synchronization

Precision & Isolation: High measurement accuracy up to ±0.1% full scale; built-in circuit isolation design to resist industrial electromagnetic interference and ensure signal authenticity

Wiring Mode

It adopts standard front screw terminal hard wiring mode with clear power and signal polarity marking to avoid wiring errors. Independent terminals are configured for sensor signal input, power supply and system signal output respectively. Power circuits and signal circuits are separated during wiring to prevent electromagnetic crosstalk. Shielded cables are recommended for analog signal wiring to enhance long-distance transmission stability and anti-interference capability.

Compatibility & Matching Accessories

It is fully compatible with Honeywell Experion PKS DCS systems and supporting gas detection sensors and monitoring units. Standard supporting accessories include dedicated DIN mounting guide rails, terminal insulating baffles, fixed fasteners and signal adapter terminals. It supports original Honeywell standard accessories and qualified third-party compatible accessories for system assembly, equipment maintenance and functional upgrading.

Application Scenarios

It is mainly applied to gas detection and process signal monitoring in petrochemical, oil and gas, chemical, pharmaceutical and energy industries. It serves as the core signal acquisition and processing module for flammable and toxic gas monitoring systems, realizing real-time gas concentration detection, fault early warning and safety interlock protection. It is also widely used for analog signal collection and accurate process control in various hazardous industrial automation control systems.

Core Product Advantages

This module features high-precision signal acquisition capability and stable data processing performance, effectively ensuring accurate monitoring of industrial process signals. It has passed TÜV SIL2 safety certification with ultra-high operational reliability and an MTBF of more than 300,000 hours. It supports online channel calibration and hot-swap replacement without system shutdown, greatly reducing maintenance downtime. The built-in electronic tag can store complete configuration information and automatically restore parameters after replacement. Equipped with front LED status indicators, it supports real-time fault diagnosis and status viewing. Industrial-grade anti-corrosion and anti-interference design adapts to harsh industrial environments.
